Product Model
|
CloudEngine S5735-S24T4XE-V2
|
CloudEngine S5735-S24P4XE-V2
|
CloudEngine S5735-S24U4XE-V2
|
CloudEngine S5735-S48T4XE-V2
|
CloudEngine S5735-S48P4XE-V2
|
CloudEngine S5735-S48U4XE-V2
|
|||||
|
Forwarding Performance
|
132 Mpps
|
132 Mpps
|
132 Mpps
|
168 Mpps
|
168 Mpps
|
168 Mpps
|
|||||
|
Switching Capacity2
|
176 Gbps/520 Gbps
|
176 Gbps/520 Gbps
|
176 Gbps/520 Gbps
|
224 Gbps/520 Gbps
|
224 Gbps/520 Gbps
|
224 Gbps/520 Gbps
|
|||||
|
Fixed Ports
|
24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports, 2 stack ports
|
48 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports, 2 stack ports
|
|||||||||
|
PoE
|
-
|
Supported,PoE+
|
Supported，90W PoE++
|
-
|
Supported,PoE+
|
Supported，90W PoE++
|
|||||
|
Power supply type
|
1+1 power supply backup
|
3 power supplies, N+1 power supply backup
|
3 power supplies, N+1 power supply backup
|
1+1 power supply backup
|
3 power supplies, N+1 power supply backup
|
3 power supplies, N+1 power supply backup
|
|||||
|
MAC Features
|
MAC address auto-learning and aging
Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses Interface-based MAC address learning limiting |
||||||||||
|
VLAN
|
4094 VLANs
Voice VLAN MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports |
||||||||||
|
IP Routing
|
Static route, RIPv1/v2, RIPng, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+, VRRP, and VRRP6
|
||||||||||
|
Interoperability
|
VBST (compatible with PVST/PVST+/RPVST)
LNP (similar to DTP) For detailed interoperability certifications and test reports, click HERE. |
||||||||||
